Polinovel 12V small batteries are high-performance batteries built on proven lithium iron phosphate chemistry. They feature an advanced battery management system that keeps the battery running at peak performance while avoiding overcharging, over-discharging, and maximizing cycle life.
Model | HD1206 |
Nominal Voltage | 12.8V |
Nominal Capacity | 6Ah |
Standard Charge Voltage | 14.6V |
Discharge Cut-off Voltage | 10V |
Max Charge Current | 6A |
Max. Constant Discharge Current | 9A |
Peak Discharge Current | 15A @5s |
Dimension (L*W*H) | 151*65*94mm / 5.9*2.6*3.7in |
Weight | 0.7kg / 1.5lbs |
Cycle Life | >2500 (1C@ DOD100%); >4000 (0.2C@ DOD100%) |
Series Parallel Application | Up to 4 units in series or 2 units in parallel |
Charge Temperature | 0 to 60ºC |
Discharge Temperature | -20 to 60ºC |
Storage Temperature | 10 to 45ºC |
