This 24V 315Ah traction battery is a high-performance LiFePO4 battery solution that can function efficiently in dusted or wet working environments and provide dependable power for uninterrupted operation. It is a perfect upgrade for floor scrubbers, sweepers, and other floor cleaning machines.
Advanced BMS Protection
This lithium traction battery features a smart BMS which allows for constant monitoring of the battery's performance, cell balancing, and multiple safety features such as protection against overcharging, over-discharging, overheating, short circuits, etc.
Consistent Power
The battery delivers high performance power and battery voltage consistently throughout the entire charge. The flat discharge curve and high sustained voltage result in efficient operation for the floor cleaning machines.
High Charging Efficiency
It can be charged up during a break without damaging the battery. Opportunity charging reduces the time required for charging and improves working efficiency.
No Maintenance
This LiFePO4 traction battery requires zero maintenance, helps reduce costly battery replacements and minimize downtime, thereby increasing efficiency and reducing the total cost of ownership.
Specification
Model | EC24315 |
Nominal Voltage | 25.6V |
Nominal Capacity | 315Ah |
Energy | 8046Wh |
Charge Voltage | 29.2V |
Discharge Cut-off Voltage | 20V |
Standard Charge Current | 30A |
Max. Charge Current | 60A |
Max. Constant Discharge Current | 100A |
Peak Discharge Current | 200A |
Dimension (LxWxH) | 600*350*264 mm (23.6*13.8*10.4 in) |
Weight | 60 kg (132 lbs) |
Battery Cell | Prismatic |
Battery Type | LiFePO4 |
Battery Case | Iron |
Terminal | M8 |
Charge Temperature | 0 to 45 ºC |
Discharge Temperature | -20 to 60 ºC |
Storage Temperature | -20 to 40 ºC |
