Fast Charging 24V 206Ah Deep Cycle Lithium Battery For Forklift

Home » Products » Forklift Battery » Fast Charging 24V 206Ah Deep Cycle Lithium Battery For Forklift

Fast Charging 24V 206Ah Deep Cycle Lithium Battery For Forklift

LiFePO4 battery ensures high performance and extended runtime
High discharge current for high efficiency
Intelligent BMS provides overcharge/overdischarge/overcurrent protections
Customizable battery size for easy installation


Availability:



Inquiry Now

Product Description

This 24V 206Ah lithium battery utilizes high-quality LFP cells for consistent power, fast charging efficiency, long life and zero maintenance. It is a superior battery solution for many motive power and material handling applications, such as forklifts, stackers, reach trucks, lift trucks, order pickers, tow motors, pallet jacks, AGVs and more.

FL24206

Intelligent BMS Protection

This industrial lithium battery features a smart BMS with multiple safety features such as protection against overcharging, over-discharging, overheating, short circuits, etc., which guarantees safe and reliable operation. What's more, the BMS embeds an advanced balancing algorithm that regulates the voltage of each cell, making sure that every cell maintains a consistent voltage level, thus ensuring optimized battery performance.

Consistent Power

The battery delivers high performance power and battery voltage consistently throughout the entire charge. The flat discharge curve and high sustained voltage result in faster operation and increased productivity for the forklifts.

High Charging Efficiency

It can be charged at any time without impacting its lifespan, for instance during a break or shift changes. Opportunity charging reduces the time required for charging and improves operation efficiency.

No Maintenance

This LiFePO4 traction battery requires zero maintenance, helps minimize downtime and streamline operations, thereby increasing efficiency and reducing overall costs.

Specification

Model	FL24206
Nominal Voltage	25.6V
Nominal Capacity	206Ah
Energy	5273Wh
Recommend Charge Voltage	29.2V
Discharge Cut-off Voltage	20V
Standard Charge Current	40A
Max. Charge Current	100A
Max. Constant Discharge Current	150A
Peak Discharge Current	200A @30s
Dimension	550150530 mm (21.75.920.9 in)
Weight	50 kg (110 lbs)
Cycle Life @DOD100%	≥2000 cycles
Charge Temperature	0~45ºC
Discharge Temperature	-20~55ºC
Storage Temperature	10~45ºC

forklift-battery-detail

Polinovel Lithium Battery Benefits

High Quality Battery Cells

Adopt top-grade lithium iron phosphate battery cells that offer significant advantages, including improved charging efficiency, zero maintenance and the ability to deep discharge while maintaining power.

Long Cycle Life

Polinovel lithium batteries provide reliable and adequate power for deep cycle use over a long period of time. The extended lifespan makes

the batteries an excellent choice for many applications that require long-lasting power.

Advanced Safety Features

The built-in BMS protects the battery from extreme temperatures, overcharging, over-discharging, and short circuits to ensure

durability and reliability.

Solid Product Warranty

Polinovel is a reputable LFP battery supplier

that offer a reliable warranty that covers the performance and life of the battery products, giving consumers peace of mind knowing that they can trust the quality of Polinovel lithium batteries.

Built-in BMS Protection

Over Charge/Discharge Protection

Monitors the battery voltage and ensures that it does not exceed or fall below a certain value to prevent over charge/discharge.

Temperature Protection

Monitors the temperature of each cell and protects the battery if the temperature exceeds/goes below a preset threshold.

Short Circuit Protection

Interrupts the flow of electricity to prevent any further damage after detecting a short-circuit.

Cell Balancing

Ensures all the cells are kept at the same voltage or SOC and helps to extend the life of the battery.

Polinovel Promises

High-performance Battery Solutions

Our team of experts thoroughly analyzes market needs and actively explores new technologies to create innovative lithium battery solutions. Our lithium ion battery products are manufactured using state-of-the-art technology and strict quality control measures to ensure they offer superior performance and great reliability.

Quality Assurance

As a reliable Li ion battery supplier, we offer products that meet global standards. Our lithium battery products are certified with CE, MSDS, RoHS, and UN38.3 certifications. When you opt for our products, be assured that quality and safety is our utmost concern.

Exceptional Customer Service

Our commitment is to provide excellent customer service from beginning to end. Our team has a wealth of experience and is focused on providing the most satisfying experience for our customers. We offer quick and effective service, whether it's responding to product inquires, assisting with orders, or dealing with technical issues.

On-time Delivery

As an experienced LFP battery supplier in the industry, we have an exceptional supply chain system and fast logistics. We are committed to providing efficient delivery to ensure that our customers receive their orders on time.
