Electrical Parameter | Model | Blue |
Nominal Voltage | 12.8V | |
Nominal Capacity | 100Ah | |
Energy | 1280Wh | |
Internal Resistance | ≤20mΩ | |
Chemistry | LiFePO4 (Lithium Iron Phosphate) | |
Cycle Life | >2000 cycles @ 1C 80% DOD | |
Self Discharge | <3%/month | |
Charge Rate | 100% | |
Discharge Rate | 100% | |
Expandable Connection | 4pcs in Series or Parallel | |
Charge Parameter | Charge Voltage | 14.6V |
Charge Current | 20A-100A | |
Max. Charge Current | 100A | |
Charge Method | CC/CV | |
Discharge Parameter | Constant Discharge Current | 100A |
Pulse Discharge Current | 200A (<5s) | |
Discharge Cut-ioff Voltage | 10V | |
Machanical Parameter | Battery Case | ABS |
Approx. Dimension | 329*172*214mm | |
Approx. Weight | 14.3kg | |
Terminal | M8 | |
Environmental Parameter | Charge Temperature | 0~45ºC (32 to 113ºF) |
Discharge Temperature | -20~60ºC (-4 to 140ºF) | |
Storage Temperature | -20~45ºC (-4 to 113ºF) | |
IP Class | IP65 |
