Model | SPI-6.5K-UP |
INVERTER OUTPUT |
Rated Output Power | 6500W |
Max.Peak Power | 13000W |
Rated Output Voltage | 120/240Vac(single-phase/split-phase) |
Rated AC Frequency | 50/60Hz |
Waveform | Pure sine wave |
Switch Time | 10ms (typical value) |
Parallel Capacity | 1～6 units |
BATTERY |
Battery Type | Lithium-ion battery/user-defined battery |
Rated Battery Voltage | 48Vdc |
Battery Voltage Range | 40～60Vdc |
Max. Mains / Generator Charging
Current | 80A |
Max. Hybrid Charging Current | 140A |
PV INPUT |
Num. of MPPT Trackers | 2 |
Max. PV Array Power | 5000W+5000W |
Max. Input Current | 18+18A |
Max. Open Circuit Voltage | 550Vdc+550Vdc |
MPPT Voltage Range | 150~450Vdc |
UTILITY/ GENERATOR INPUT |
Input Voltage Range | 65~140Vac |
Frequency Range | 50/60Hz |
Bypass Overload Current | 40A |
EFFICIENCY |
MPPT Tracking Efficiency | 99.90% |
Max. Battery Inverter Efficiency | 93% |
GENERAL INFORMATION |
Dimensions | 584.6*410*133 mm (23*16.1*5.2 in) |
Weight | 18.9 kg (42lbs) |
Protection | IP20, for indoor use only |
Operating Temperature Range | −10°C~55°C, >45°C derating |
Noise | <60 dB |
Cooling Method | Intelligent fan |
Warranty | 24 Months |
COMMUNICATION |
Embedded Interfaces | RS485/CAN/USB/dry contact |
External Modules（Optional） | Wi-Fi / GPRS |
CERITIFACATION |
Safety | IEC62109-1, IEC62109-2, and UL1741 |
EMC | EN61000-6-1, EN61000-6-3, and FCC 15 class B |
RoHS | Yes |
