Polinovel CBS240 Outdoor Cabinet Battery Energy Storage System is tailored for high capacity power storage, ideal for large-scale renewable energy generation, PV self-consumption, off-grid applications, peak shaving, and emergency backup power.
Turnkey Energy Storage Solution
This battery energy storage system integrates LiFePO4 battery units, PCS (Power Conversion System), EMS (Energy Management System), STS (Static Transfer Switch), high voltage control box, DC-DC unit, air/liquid cooling system, fire extinguishing system, etc., offering an efficient solution for large-scale power storage needs.
Modular System Configuration
The system features a modular design for easy maintenance and exceptional flexibility, making it perfect for use in new energy storage, smooth load fluctuations, peak shaving and frequency regulation for power grid, peak shaving and valley filling in industrial and commercial energy storage, improve power supply reliability of microgrids and isolated grids.
High Safety and Reliability
This system incorporates top-grade LiFePO4 batteries with long life, good consistency and superior charging and discharging performance. Moreover, with efficient thermal management design and fire protection system, it ensures reliable performance and the highest level of safety.
Designed for All Weather Use
This advanced battery energy storage system is built with robust industrial housing, offering exceptional durability and protection. Designed to endure harsh weather conditions, it ensures reliable performance in outdoor environments.
Specification
Battery Parameter | |
Model | CBS240 |
Rated Voltage | 768V |
Rated Capacity | 314Ah |
Energy | 241KWH |
Operating Voltage Range | 624-864V |
Series and Parallel Connection | 1P240S |
System Parameter | |
Grid Standard | 3L+N+PE |
Rated Power | 125KW |
Grid Voltage Range | 380V (-15% to +10%) |
Rated Current | 190A |
Maximum Conversion Efficiency | 97% |
Over-loading Ability | 110% 1min |
Rated Frequency | 50hz |
Grid Frequency Range | 50hz±2.5hz |
Grid Total Distortion Rate | ≤3 fully loading |
Three-phase Unbalance Degree | 100% |
Power Factor | 1 |
General Parameter | |
Cooling System | Liquid cooling |
Fire Extinguishing System | Perfluoro |
Operating temperature | -20~50℃ |
Noise | ≤60dB |
IP Grade | IP54 |
Size (W*D*H) | 1195*1400*2140mm (47.1*55.1*84.3in) |
Weight | ≤2.8ton |
