| Model | HV19250 | HV192100 | HV24050 | HV240100 | HV38450 | HV384100 | HV48050 | HV480100 |
| Nominal Voltage | 192V | 192V | 240V | 240V | 384V | 384V | 480V | 480V |
| Nominal Capacity | 50Ah | 100Ah | 50Ah | 100Ah | 50Ah | 100Ah | 50Ah | 100Ah |
| Energy | 9.6kWh | 19.2kWh | 12kWh | 24kWh | 19.2kWh | 38.4kWh | 24kWh | 48kWh |
| Charge Cut-off Voltage | 218V | 218V | 200V | 200V | 435V | 435V | 545V | 545V |
| Discharge Cut-off Voltage | 160V | 160V | 270V | 270V | 320V | 320V | 400V | 400V |
| Recommended Charge Current | 25A | 50A | 25A | 50A | 25A | 50A | 25A | 50A |
| Max. Charge Current | 50A | 100A | 50A | 100A | 50A | 100A | 50A | 100A |
| Max. Constant Discharge Current | 50A | 100A | 50A | 100A | 50A | 100A | 50A | 100A |
| Peak Current | 100A | 200A | 100A | 200A | 100A | 200A | 100A | 200A |
| Communication | RS485/CAN | RS485/CAN | RS485/CAN | RS485/CAN | RS485/CAN | RS485/CAN | RS485/CAN | RS485/CAN |
| Dimension | 460*330*480 mm (18.1*13*18.9 in) | 600*600*1600 mm (23.6*23.6*63 in) | 460*330*640 mm (18.1*13*25.2 in) | 1530*600*600 mm (60.2*23.6*23.6 in) | 460*330*780 mm (18.1*13*30.7 in) | 600*600*1600 mm (23.6*23.6*63 in) | 600*600*1600 mm (23.6*23.6*63 in) | 1200*600*1600 mm (47.2*23.6*63 in) |
| Weight | 100 kg (220.5 lbs) | 190 kg (418.9 lbs) | 170 kg (374.8 lbs) | 260 kg (573.2 lbs) | 280 kg (617.3 lbs) | 500 kg (1102.3 lbs) | 350 kg (771.6 lbs) | 600 kg (1322.8 lbs) |
| Charge Temperature | 0~50 °C | 0~50 °C | 0~50 °C | 0~50 °C | 0~50 °C | 0~50 °C | 0~50 °C | 0~50 °C |
| Discharge Temperature | -15~ 60°C | -15~ 60°C | -15~ 60°C | -15~ 60°C | -15~ 60°C | -15~ 60°C | -15~ 60°C | -15~ 60°C |
