Electric Boat 12V 200Ah HT Lithium Battery with Bluetooth

Free download APP on Android and iOS phones
Bluetooth monitoring battery working status
“BMS + Safe Board” dual protection
The patented screw fastening structure
Good performance in harsh environment
Intelligent battery management system
Support series or parallel connection
Effective customize the technical solution
High quality and punctual delivery
Trustworthy innovative lithium battery manufacturer


Availability:



Inquiry Now

Product Description

The HT series is part of our range of lithium iron phosphate batteries, which combine proven lithium iron phosphate technology, intelligent Battery Management System (BMS), and Bluetooth connectivity. The Bluetooth lithium battery delivers longer-lasting power and can be monitored via smartphones and other smart devices.

The 12.8V 200Ah smart battery is ideal for users in hard-to-access locations or in critical applications where the battery needs to be regularly checked for peak performance.

polinovel-ht-app

ELECTRICAL SPECIFICATIONS
Model	HT12200
Nominal Voltage	12.8V
Nominal Capacity	200Ah
Energy	2560Wh
Self Discharge	<3%/month
Maximum Modules in Series or Parallel	4
MECHANICAL SPECIFICATIONS
Dimensions (L x W x H)	520 x 240 x 220 mm (20.5 x 9.4 x 8.7”)
Weight	27.8kg (61 lbs)
Terminal Type	M8
Case Material	ABS
Enclosure Protection	IP56
Cell Type	Cylindrical
Chemistry	LiFePO4
CHARGE SPECIFICATIONS
Recommended Charge Current	40A-100A
Maximum Charge Current	100A
Charge Current (0 to -10 ºC)	≤0.1C
Charge Current (-20 to -10 ºC)	≤0.05C
Recommended Charge Voltage	14.2V – 14.6V
BMS Charge Voltage Cut-Off	15.4V (3.85 ±0.025 vpc, 1~1.5s)
Reconnect Voltage	15V (3.75 ±0.05vpc) / 15.2V (3.8 ±0.05vpc)
DISCHARGE SPECIFICATIONS
Maximum Continuous Discharge Current	160A (or 100A)
Peak Discharge Current	320A/5s (or 200A/5s)
BMS Discharge Current Cut-Off	400A/9ms (300A/9ms)
Recommended Low Voltage Disconnect	10V
BMS Discharge Voltage Cut-Off	8V (2.0±0.05vpc, 120~180ms)
Reconnect Voltage	9.2V (2.3±0.1vpc)
TEMPERATURE SPECIFICATIONS
Discharge Temperature	-20 to 60 ºC (-4 to 140 ºF)
Charge Temperature	0 to 45 ºC (32 to 113 ºF)
Storage Temperature (1 month)	-20 to 60 ºC (-4 to 140 ºF)
Storage Temperature (3 months)	-20 to 45 ºC (-4 to 113 ºF)
Storage Temperature (6 months)	-20 to 25 ºC (-4 to 77 ºF)
COMPLIANCE SPECIFICATIONS
Certifications	CE, UN38.3, MSDS
Shipping Classification	UN 3480, CLASS 9

Polinovel Lithium Battery Benefits

High Quality Battery Cells

Adopt top-grade lithium iron phosphate battery cells that offer significant advantages, including improved charging efficiency, zero maintenance and the ability to deep discharge while maintaining power.

Long Cycle Life

Polinovel lithium batteries provide reliable and adequate power for deep cycle use over a long period of time. The extended lifespan makes

the batteries an excellent choice for many applications that require long-lasting power.

Advanced Safety Features

The built-in BMS protects the battery from extreme temperatures, overcharging, over-discharging, and short circuits to ensure

durability and reliability.

Solid Product Warranty

Polinovel is a reputable LFP battery supplier

that offer a reliable warranty that covers the performance and life of the battery products, giving consumers peace of mind knowing that they can trust the quality of Polinovel lithium batteries.

Built-in BMS Protection

Over Charge/Discharge Protection

Monitors the battery voltage and ensures that it does not exceed or fall below a certain value to prevent over charge/discharge.

Temperature Protection

Monitors the temperature of each cell and protects the battery if the temperature exceeds/goes below a preset threshold.

Short Circuit Protection

Interrupts the flow of electricity to prevent any further damage after detecting a short-circuit.

Cell Balancing

Ensures all the cells are kept at the same voltage or SOC and helps to extend the life of the battery.
